錘式破碎機是由錘式破碎機箱體、轉子、錘頭、反擊襯板、篩板等組成。主要用于在水泥，化工，電力，冶金等工業部門破碎中等硬度的物料。
錘式破碎機由上殼體、下殼體、傳動部件、篩板部件等組成。
錘式破碎機適用于破碎抗壓強度180MPa以下的石灰石、煤矸石、石膏、頁巖等各類中硬脆性物料的粗、中、細碎作業。錘式破碎機是直接將z大粒度為600-1800毫米的物料破碎至25或25毫米以下的一段破碎用破碎機。
錘式破碎機適用于在水泥、化工、電力、冶金等工業部門破碎中等硬度的物料，如石灰石、爐渣、焦碳、煤等物料的中碎和細碎作業。單段錘式破碎機為重錘式破碎機，又叫復合錘式破碎機，主要用于石灰石的破碎作業，大型單段錘式破碎機可以將1米直徑的石灰巖直接破碎到20mm左右，具有強大的破碎能力。單段錘式破碎機在水泥行業具有大量的應用。
錘式破碎機主要是靠沖擊能來完成破碎物料作業的。錘式破碎機工作時，電機帶動轉子作高速旋轉，物料均勻的進入破碎機腔中，高速回轉的錘頭沖擊、剪切撕裂物料致物料被破碎，同時，物料自身的重力作用使物料從高速旋轉的錘頭沖向架體內擋板、篩條，在轉子下部，設有篩板、粉碎物料中小于篩孔尺寸的粒級通過篩板排出，大于篩孔尺寸的物料阻留在篩板上繼續受到錘子的打擊和研磨，直到破碎至所需出料粒度z后通過篩板排出機外。
Hammer crusher, Hammer crusher price, Crushing equipment product library - Henan Ruilang Machinery
A hammer crusher is composed of a hammer crusher housing, rotor, hammer head, impact lining plate, sieve plate, etc. Mainly used for crushing medium hardness materials in industrial sectors such as cement, chemical, power, metallurgy, etc.
The hammer crusher consists of an upper shell, a lower shell, transmission components, sieve plate components, etc.
The hammer crusher is suitable for crushing various types of medium hard and brittle materials such as limestone, coal gangue, gypsum, shale, etc. with compressive strength below 180MPa in coarse, medium, and fine crushing operations. A hammer crusher is a crushing machine used to directly crush materials with a maximum particle size of 600-1800 millimeters to 25 or less millimeters.
Hammer crushers are suitable for crushing medium hardness materials such as limestone, slag, coke, coal, etc. in industrial sectors such as cement, chemical, power, metallurgy, etc. The single-stage hammer crusher is a heavy hammer crusher, also known as a composite hammer crusher, mainly used for limestone crushing operations. Large single-stage hammer crushers can directly crush limestone with a diameter of 1 meter to about 20mm, with strong crushing capacity. Single stage hammer crushers have a wide range of applications in the cement industry.
Hammer crushers mainly rely on impact energy to complete material crushing operations. When the hammer crusher is in operation, the motor drives the rotor to rotate at high speed, and the material uniformly enters the crusher chamber. The high-speed rotating hammer head impacts, shears and tears the material, causing it to be crushed. At the same time, the gravity of the material itself causes the material to rush from the high-speed rotating hammer head to the baffle and screen strip inside the frame. At the lower part of the rotor, there is a sieve plate, and the particles smaller than the sieve hole size in the crushed material are discharged through the sieve plate. The materials larger than the sieve hole size are retained on the sieve plate and continue to be hit and ground by the hammer until they are crushed to the required discharge particle size and finally discharged outside the machine through the sieve plate.
